Understanding Encoders | White Paper

Encoders are used to determine the position, velocity and direction of a motor shaft or other mechanical motion. They provide information required for the precise control of a variety of applications, such as positioning a rotary table, pick and place, machine assembly, packaging, robotics and more. Regardless of type, all encoders provide a method of orientation detection that’s used as a reference point for position control.

PLC PAC WP Full

An encoder (for industrial controls) is a special sensor that captures position information and relays that data to other devices. The position information can be determined using one of three technologies: optical, magnetic or capacitive.

Optical encoders are the most accurate of the standard styles of encoders. When choosing an optical encoder, it’s important that the encoder has extra protections
built in to prevent contamination from dust, vibration and other conditions common to industrial environments.

Magnetic encoders are more rugged than optical encoders and often used in environments in which dirt, steam, vibration and other factors could interfere with optical encoder performance. Magnetic encoders cannot achieve the resolution or accuracy of optical encoders.

Capacitive encoders are relative newcomers as an industrial sensing technology. These encoders are as rugged as magnetic encoders but also do not achieve the high resolutions of optical encoders. For more download the free white paper.
